| Parameter/Type | TRS4-D10 | TRS4-D20 | TRS4-C40 | TRS4-B60 |
| Nominal volatge Un | 230 V AC | |||
| Maximum operating voltage Uc | 275 V AC | |||
| Nominal discharge current (8/20μs) In | 5 kA | 10 kA | 20 kA | 30 kA |
| Maximum discharge current (8/20μs) Imax | 10 kA | 20 kA | 40 kA | 60 kA |
| Voltage protection level Up | ≤ 0,7 kV | ≤ 1,0 kV | ≤ 1,3 kV | ≤ 1,5 kV |
| Response time ta | < 25ns | |||
| Cross-section of connected conductors solid (min/max) | 16 mm2 / 35 mm2 | |||
| Cross-section of connected conductors stranded (min/max) | 16 mm2 / 35 mm2 | |||
| Fault indication | red indication field | |||
| Remote indication | potential-free change-over contact | |||
| Remote indication contacts | 250 V / 0,5 A AC, 250 V / 0,1 A DC | |||
| Cross-section of remote indication conductors | 1,5 mm2 | |||
| Degree of protection | IP20 | |||
| Range of operating temperatures (min/max) | -40℃~+70℃ | |||
| Humidity range | 5%~95% | |||
| Mounting | DIN rail 35 mm | |||
| According to standard | EN 61643-11:2012, IEC 61643-11:2011 / T2 | |||
| Remarks | Other Uc can be customized.(420V AC, 385V AC, 320V AC, et | |||
