TRSS-RJ45-24 Rack-mounted Network Signal Surge Protector

  1. Indeally suited for retrofitting, protection of all lines
  2. For installation in conformity with the lightning protection zone concept at the boundaries from 0B -2 and higher
Catalogue-Surge Protective Devices
Parameter/Type TRSS-RJ45 TRSS-RJ45/16
For 19” Cabinet Rack
TRSS-RJ45/24
For 19” Cabinet Rack
Material/Ports numbers PA66/Aluminum/single port Aluminum/16 ports Aluminum/24 ports
Nominal volatge                                                 Un 48 V
Maximum operating voltage (d.c.)                       Uc 50 V
Maximum operating voltage (a.c.)                       Uc 34 V
Maximum operating voltage (d.c.) pair-pai(PoE)   Uc 57 V
Nominal current                                                   IL 1 A
Current flow (8/20μs)(L-L) 5 kA
Current flow (8/20μs)(L-PE) 10 kA
Voltage protection level (L-L)                               Up  60 V
Voltage protection level  (L-PE)                            Up 500 V
Cut-off frequency 250 MHz
Insertion loss at 250 MHz (1000Mpbs) ≤ 0,5 dB
Connection (input/ output) RJ45 socket/ RJ45 socket
Pinning Data:1/2/3/6; PoE:4/5/7/8
Response time                                                     ta 25ns
Degree of protection IP20
Range of operating temperatures (min/max) -40℃/70℃
Humidity range 5%-95%
According to standard EN 61643-21:2012, IEC 61643-21:2011
