Main
| Product or component type | Miniature circuit-breaker |
| Device application | Distribution |
| Poles description | 4P |
| Number of protected poles | 4 |
| Network type | DC |
| Trip unit technology | Thermal-magnetic |
| Curve code | C |
| Breaking capacity | 6kA |
Complementary
| rated operational voltage (Ue) | 500V DC | |
| Control type | Toggle | |
| Local signalling | ON/OFF indication | |
| Mounting mode | Clip-on | |
| Mounting support | DIN rail 35mm | |
| Colour | Grey | |
| Endurance (O-C) | Electrical | 10 ,000 cydes |
| Mechanical durability | 20 ,000 cycles | |
Environment
| Standards | IEC 60947-2 |
| IP degree of protection | IP40 for modular enclosure conforming to IEC 60529 |
| IP20 conforming to IEC 60529 | |
| Operating altitude | 2000m |
| Ambient air temperature for operation | -35 ° C to +70 ° C |
| Ambient air temperature for storage | -40 ° C to +85 ° C |
Catalog numbers
| Type | Width 9 mmmodules | |||
| 4P | Rating(ln) | C Curve | D Curve | 8 |
 |
1A | TRMX6-63DC/ 1/C1 | TRMX6-63DC/ 1/ D1 | |
| 3A | TRMX6-63DC/ 1/C3 | TRMX6-63DC/ 1/ D3 | ||
| 5A | TRMX6-63DC/ 1/C5 | TRMX6-63DC/ 1/ D5 | ||
| 6A | TRMX6-63DC/ 1/C6 | TRMX6-63DC/ 1/ D6 | ||
| 10A | TRMX6-63DC/ 1/C10 | TRMX6-63DC/ 1/ D10 | ||
| 16A | TRMX6-63DC/ 1/C16 | TRMX6-63DC/ 1/ D16 | ||
| 20A | TRMX6-63DC/ 1/C20 | TRMX6-63DC/ 1/ D20 | ||
| 25A | TRMX6-63DC/ 1/C25 | TRMX6-63DC/ 1/ D25 | ||
| 32A | TRMX6-63DC/ 1/C32 | TRMX6-63DC/ 1/ D32 | ||
| 40A | TRMX6-63DC/ 1/C40 | TRMX6-63DC/ 1/ D40 | ||
| 50A | TRMX6-63DC/ 1/C50 | TRMX6-63DC/ 1/ D50 | ||
| 63A | TRMX6-63DC/ 1/C63 | TRMX6-63DC/ 1/ D63 | ||
