| Model | TRSC-1 |
| Discharge response | ≥2ka (rising ≥8μS) |
| Counting interval | ≥2ns |
| External power supply | 220V~ |
| backup power | 5~ 12V~/- |
| Electric power | ≤0.5W |
| Memory Function One | No data loss when power off |
| Clear the number of discharges | Long press (>8s) |
| Discharge times preset | Press for 00.5s lift up, ac-cumulatively 1 time |
| Scope of wheat owing | 0~9999 number |
| Switch input 1 display | The first decimal point from the left, open circuit is not bright, closed circuit is bright |
| Switch input 2 display | The second decimal point from the left, open circuit is not bright, closed circuit is bright |
| Switch input parameters | Passive dry contact access, the access resistance is less than 200Ω |
| CPU work display | 1st decimal point from right |
| CPU working status | Normal decimal point flashes |
| Data output one | RS485 (M od bu s communication protocol) |
| Working temperature zone | -40°C~70°C |
| Wiring specifications | 0.5mm2~ 1.5mm2 |
| Shell material one | Flame retardant plastic |
| Magnetic ring size one | 22mm × 1 4mm ×8mm |
| Mounting brackets | 35mm Din rail |
| Enclosure rating | IP20 |
